PAVO P-3080i

On-Counter Presentation 2D Barcode Scanner

PAVO P-3080i
PAVO P-3080i
PAVO P-3080i
PAVO P-3080i
PAVO P-3080i
  • PAVO P-3080i
  • PAVO P-3080i
  • PAVO P-3080i
  • PAVO P-3080i
  • PAVO P-3080i

Features

The PAVO P-3080i is an on counter 2D bar code scanner, it uses digital imaging technology to provide intuitive and blazing reading of 1D and 2D bar codes without sacrificing scanning quality or performance. The P-3080i reader provides great performance and reliability along with a rich feature set to provide excellent value in virtually any desktop presentation barcode scanning system. With the P-3080i, not only can identify product pricing barcode label, furthermore, it is able to scan virtually any mobile bar code on various types of display to enhance service levels. The P-3080i reader includes a powerful configuration tool which allows easy integration into existing or new host systems. Its precise imaging scan volume is perfect for hands-free scanning in confined spaces and helps reduce accidental misreads of items, provides instant and accurate scanning, making the checkout process more efficient for you and more convenient for your customers.

  • Read most 1D, 2D, composite and stacked codes, reduce your investment cost.
  • Wider reading field of view.
  • Sharp wake-up detection.
  • High-speed movement tolerance of 1 m/s, suitable for high-traffic scanning requirements.
  • The bottom and back designs are designed to be fixed or hung and positioned to meet different installation requirements.
  • Boost customer services with good ability to scan mobile bar code on various types of display.
  • Great reading performance and best cost-effective investment.
  • 1D Codes
  • 2D Codes
  • GS1

  • PAVO P-3080i

    PAVO P-3080i

  • Compare to

Tech Specs

Environmental

Operating temperature Storage temperature Humidity Ambient light
-20°C/-4°F to 50°C/122°F -40°C/-40°F to 60°C/140°F 5% to 95% (Non-condensing) 100,000 Lux Max. (Sunlight)
- - - - - -20°C to 50°C ( -4°F to 122°F ) -20°C to 40°C ( -4°F to 104°F ) - - - - - - -40°C to 60°C ( -40°F to 140°F ) -40°C to 70°C ( -40°F to 158°F ) - - - - - - 5% to 95% (Non-condensing) 5% to 95% (Non-condensing) - - Up to 100,000 Lux (direct sunlight) Up to 100,000 Lux (direct sunlight) - - 100,000 Lux Max. (Sunlight) 100,000 Lux Max. (Sunlight) -

Specifications

Material Dimension(WxDxH) Light Source Filed of View Resolution Pitch Skew Roll Indicators Print Contrast Ratio Readable Barcodes
ABS 152mm(W) x 153.2mm(H) x 84.12mm(L) Visible red light 625nm LED Horizontal 62°× Vertical 41° 1280 (H) x 800 (V) pixels ±70° (from front to back) ±65° (from plane parallel symbol side-to-side) ±180° Beeper and LED ≥20% 1D Symbologies UPC-A, UPC-E, EAN-8, EAN-13, Code 128, GS1-128, Code 39, Code 32, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5 (Straight 2 of 5), Standard 2 of 5（IATA 2 of 5）, Codabar（NW-7）, MSI, GS1 Databar(Omnidirectional, Limited, Expanded), China Post, Tepepen, GS1 Composite.; 2D Symbologies QR Code, Micro QR Code, Data Matrix, PDF417, Micro PDF 417, MaxiCode, Aztec, HanXin Code, Chinese ID Card OCR.
- - - - - ABS Plastic ABS Plastic - - 152x152x90.2mm 152x152x91mm 97.89 x 74.89 x 137.64 mm 97.89 x 74.90 x 137.94 mm 96.7 x 86.7 x 143.6 mm 77 x 100 x 123 mm - - Visible red light 625nm LED 625±10nm Red LED Visible White LED Visible White LED Red LED White Light LED - - 80° Horizontal, 55° Vertical Horizontal: 40°, Vertical: 25° Horizontal – 55°, Vertical – 35° (dual faces) Horizontal – 55°, Vertical – 35° Horizontal – 41°, Vertical – 31° Horizontal – 38°, Vertical – 30° - - 3 mil / 0.076mm 1D: 4mil/0.1mm, 2D: 8mil/0.2mm 1280 (H) x 800 (V) pixels; 3.0 mil (Code 39), 8 mil (QR Code) 3.0 mil (Code 39), 8 mil (QR Code) 640 (H) x 480 (V) pixels, ≥5mil/0.127mmPCS90%,CODE 39) 1D: 4.0 mil/0.1mm, 2D: 6.67mil/0.17mm - - ±60° (from front to back) - - - - ±60°(from front to back) - - ±60° (from plane parallel symbol side-to-side) - - - - ±60°(from plane parallel to symbol(side- to-side)) - - ±180° - - - - 360° - - Beeper and LED Beeper and LED Beep and LED (Standby Orange, Good read Blue) Beep and LED Beep and LED Beep - - - 25% - - >= 25% >= 20% - - - - - - 1D Symbologies UPC-A，UPC-E，EAN-8，EAN-13，Code 128， GS1-128， Code 39，Code 32, Code 93，Code 11，Interleaved 2 of 5，Matrix 2 of 5，Industrial 2 of 5(Straight 2 of 5)，Standard 2 of 5（IATA 2 of 5）,Codabar（NW-7），MSI，GS1 Databar(Omnidirectional, Limited, Expanded)，China Post, Tepepen, GS1 Composite etc. 2D Symbologies QR Code, Micro QR Code, Data Matrix，PDF417, Micro PDF 417， MaxiCode, Aztec，HanXin Code, Chinese ID Card OCR, etc - -

Weight

Body weight
Approx. 508.6g（without cable)
- - - - - Approx. 270g w/o cable Approx. 254g (with cable) -

Electrical Characteristics

Interface Power Operation (Typ.)
RS-232 or USB( HID or Virtual COM.); cable length 180cm DC 5V 280mA (work)
- RS232, USB HID or Virtual COM RS232, USB (Virtual COM) RS232, USB (HID or Virtual COM) RS232, USB(HID, Virtual COM) USB or RS-232 - - - DC 5V @2A DC 5V @2A DC 5V @2A DC 5V @2A DC 5V DC Adaptor +5V ±5% - - - - - - 280mA(work) <280mA -
Datasheet User's Manual
Download Download
